HOYUN Multi Disc Cutting Machine Video
The machine can choose different belt widths of 450mm/600mm/800mm/1200mm, which is suitable for processing plates of different sizes.
Our Advantage
Belt frequency conversion speed regulation
Customized frequency conversion speed regulation function, by reducing the spindle speed and installing the line concave and convex grinding wheel, it can have the function of profiling.
Four guide column structure
The motor lift adopts a four-guide column structure, which is more stable and will not cause vibration when multiple blades are installed.
Water-cooled spindle
The water-cooled spindle is equipped with an external water pipe to cool the spindle and blades, extending the service life of the machine.
Cutting disc/convex grinding wheel
2-12 cutting discs can be mounted at one time, or line concave-convex grinding wheels can be installed, so that one machine has multiple uses
Schneider Electric
The entire series is equipped with Schneider electrical appliances as standard to protect the motors, making them safer and more durable.
Control box with suspension arm
All series are equipped with controlbox with suspension arm as standard, which is convenient for operation.
Related Miter Cut Out
Multi-Blade Cutting Machine Parameters
| Model | HY1-450 | HY1-600 | HY1-800 | HY1-1200 |
|---|---|---|---|---|
| Cutting shaft | 1 | 1 | 1 | 1 |
| Conveyor belt width | 470mm | 620mm | 820mm | 1220mm |
| Conveyor belt speed | 0.8-4m/min | 0.8-4m/min | 0.8-4m/min | 0.8-4m/min |
| Diameter of cutting blade | Φ250-450mm | Φ250-450mm | Φ250-450mm | Φ250-450mm |
| Cutting width | 20-450mm | 20-600mm | 20-800mm | 20-120mm |
| Cutting thickness | 6-150mm | 6-150mm | 6-150mm | 6-150mm |
| Total power | 20.75KW | 20.75KW | 20.75KW | 20.75KW |
| Weight | 1050KG | 1250KG | 1450KG | 1650KG |
| Machine size | 2200*1600*1750mm | 2200*1800*1750mm | 2200*2000*1750mm | 2200*2300*1750mm |
| Package size | 2300*1700*1900mm | 2300*1900*1900mm | 2300*2100*1900mm | 2300*2350*1900mm |
